INSTALLATION And Maintenance GUIDE

---

READ INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION.

This flooring is intended for indoor use only. Residential installation does not require acclimation, as long as the floor is allowed to sit and brought up to room temperature prior to installation. Commercial installation requires a 24-hour  minimum acclimation period. Make sure the subfloor is clean, dry and flat.

Inspect ALL material carefully for color, finish, sheen and defects PRIOR to

and do not pinch planksith visible defects found after installation are not covered under warranty.

Installation implies acceptance of the quality, dimensions, and appearance of

the flooring. Should there be any doubts regarding the aforementioned aspects,

please contact your dealer/distributor and do not proceed with installation until

you are satisfied with your flooring.

OTHER THINGS TO NOTE

Samples are designed to be a representation of the actual product. Your

finished flooring may contain a varying ratio of knots, saw marks, splits, cracks,

streaks, and/or color contrast. Samples under varying light sources including

sunlight and room lighting may result in a difference of appearance of the

flooring under each condition.

While Rigid Core Vinyl (SPC) Flooring is a waterproof and fire-resistant

material, it is not meant to act as a moisture barrier for the home. It is best

practice to test for moisture and take action promptly and accordingly.

Store product boxes flat and ensure they are fully supported during shipping,

handling, and storage. Rough handling can cause damage to the flooring prior

to installation.

Rigid Core Vinyl (SPC) Flooring can be heavier than expected. Always use

proper lifting techniques with handling. Whenever possible, use material

handling equipment and/or have assistance from shipping and handling

professionals.

Avoid direct sunlight exposure to minimize the effects of fading of the flooring.

Prolonged UV exposure will likely have a uniform fading effect on building

materials.

TOOLS REQUIRED

· Power Saw

· Tape Measure

· Spacers

· Rubber Mallet

· Pencil

· Straight Edge

THINGS TO NOTE

· Do not use tape or adhesive products of any kind on the surface of the

flooring. Doing so may discolor and/or damage its finish.

· Door jambs are recommended to be undercut.

· Cabinets cannot be installed on top of flooring.

· Wall moldings and transition accessories cannot be fastened to the planks.

· Mix boards from several boxes to ensure a suitable variation of color and

shade.

JOBSITE REQUIREMENTS

Rigid Core Vinyl (SPC) Flooring has been designed to float over an existing

floor without glue or adhesive, and can be installed on, above, or below grade

level. It is the sole responsibility of the installer or homeowner to determine

whether or not jobsite and subfloor conditions are environmentally and

structurally acceptable for vinyl floor installation. The distributor and

manufacturer do not assume responsibility for vinyl floor failure to perform due

to ill-suited or ill-prepared subfloor, subsurface or other jobsite damages or

deficiencies after vinyl flooring has been installed.

Crawl spaces must be a minimum of 18" from the ground to the underside of

joists. Adequate cross ventilation must be provided (1.5% of crawl spaces D A

Ground cover of 6-20 mil polyethylene film must be provided as a moisture

barrier with a 6" overlap at the joints (sealed with moisture resistant tape).

Moisture prevention inhibits the potential growth of harmful bacteria and

stain-causing mold and mildew from the subfloor.

All installed areas must have a working heater and air conditioner to provide

normal living conditions beginning at least 48 hours prior to installation and

throughout the duration of flooring's lifespan. Normal living conditions include

indoor temperature of 65-80°F and relative humidity of 35-55%. Portable and

kerosene heaters are not recommended.

SUBFLOOR REQUIREMENTS

Rigid Core Vinyl Flooring can be installed over concrete, wood subfloors and

most other existing hard-surface floor coverings. All subfloors must be dry,

clean (swept of any debris), structurally sound and level within 1/4" per 10-foot

radius.

Wood subfloors must be suspended minimum of 18" above ground. Check if

well secured; nail or screw every 6" along joists to avoid squeaking. If subfloor

is not level, sand down high spots and fill low spots with a Portland

cement-based leveling compound.

Concrete subfloors must be fully cured for a minimum of 60 days and tested for

moisture. Concrete moisture vapor emissions should not exceed Bibs (ASTM

F1869) or 90% RH (ASTM F2170) with a pH limit of 9. For floors outside of this

range a minimum 6 mil polyfilm required between concrete and ground.

Subfloor moisture prevention limits the potential growth of harmful bacteria and

mold. If not level, grind down high spots and fill low spots with a Portland

cement-based leveling compound.

To install over existing hard-surface flooring, check to see if the existing floor is

well bonded and level to the subfloor. Apply cement based leveling compound

to level out uneven areas. Heavily cushioned vinyl flooring or vinyl flooring

consisting of multiple layers are NOT suitable subfloors for installation. Do not

sand existing vinyl as it may contain asbestos. Take proper precaution and

contact an asbestos abatement company to remove old vinyl.

RADIANT HEAT

Rigid Core Vinyl Flooring is compatible with a concrete subfloor with an in-floor

(embedded) radiant heating system. The heating system must be 1.5" below

the surface layer of the concrete slab. Prior to flooring installation, the heating

system must be operated at normal living temperatures for 14 days.

Additionally, for 24 hours before, during, and after installation, the heating unit

must be turned off. Radiant Heat systems must have failsafe capabilities to

ensure surface temperatures do not exceed 80°F.

USE OF ELECTRIC HEATING MATS AND OTHER HEATING UNITS

DIRECTLY UNDERNEATH RIGID CORE VINYL FLOORING CAN VOID

WARRANTY.

INSTALLATION GUIDELINES

Decide which direction to lay the flooring. Measure the width and length of the

room and calculate plank width of the last row. For the best aesthetic, we donot recommend plank width narrower than 2.5 inches.

Large spans in excess of 80" require expansion breaks.

1. Using Spacers: Leave a 1/4" expansion gap between walls and edges of

the flooring.

2. Installing the first row: From left to right, with the tongue-side facing the

longest wall in the room, place the first board. Note that if the first row does not

need to be trimmed in width, cut off the "tongue" so a solid straight edge is

placed along the wall. Align and angle the second board to place the end joint

tongue into the end joint groove of first board and connect the two into place.

To ensure a secure fit, gently tap the joint with a rubber mallet in a downward

angled motion towards the adjoining board. Continue installing additional

boards in this manner until reaching the final board in the first row. Measure

and cut the final board to fit the room.

3. Installing the second row onwards: You may use any left-over planks

from the first row if greater than 8" in length. If not, cut a new board at least 8"

in length and allow 8" between end joints of the previous row to the current row

that is being installed. Position the first board into place by angling and

interlocking the side tongue (long end) into the previous row. Ensure fit and lay

down gently into place. Position the next board using the same angling

technique, interlocking motion on side tongue (long end) laying down gently,

leaving a 1mm gap on the adjoining board. Tap the joint with a rubber mallet in

a downward angled motion towards adjoining board until tongue and groove

lock. Continue installing additional boards in each row in this manner. When

you reach final board in each row, measure and cut the final board in each row

to its proper length.

CONTINUALLY CHECK FOR GAPS BETWEEN BOARDS BEFORE

MOVING ON TO THE NEXT.

4. Installing the final row: Follow step 3. The final row and all corresponding

boards may need to be cut lengthwise (ripped).

5. Final step accessories: Replace the molding or wall base, allowing slight

clearance between the molding and the planks. Nail the molding to the wall

surface not through the flooring. At doorways and other areas where the

flooring planks may meet other flooring surfaces, it is preferable to use a

T-Molding, or something similar, to cover exposed edges. Check for clearance

and do not pinch planks.
